DAB – 1.5 HP K 35/100 M

SW01540207​

APPLICATIONS:

• K 35/100 - Twin-impeller centrifugal pump designed for the realization of pressurization units in water systems.
• Suitable for sprinkler systems and other general water supply uses.
• Ideal for roof and booster to provide direct water supply with complementary Pump PM 1 - 2 BAR to make Automatic Start and stop the residential pump automatically which connected directly to the interior water network
• Water transfer system with high flow rate Up to 160 liter/min
• Pumped liquid temperature range From 0 °C Up to 60°C
• Maximum ambient temperature: Up to 55°C
• Box Components : 1.5m wire attached, installation instructions guide
• Weight : 21.5 KG
• PACKING DIMENSIONS : Length: 415 mm - Width: 234 mm - Height: 295 mm
• Warranty :Years Warranty from the date of receipt
•  Country Of Origin :Made in Italy

Descriptions:

• Totally enclosed fan cooled motor for protection against rainwater and dust with degree of protection IP44.
• Built-in thermal and current overload protection
• Free of charge power cable , no need to open the terminal box to connect another cable
• Low noise.
• Easy installation.

CONSTRUCTION FEATURES OF THE PUMP:

Pump body and motor support in cast iron. Techno polymer impeller, Carbon/ceramic mechanical seal.

DAB HP 2.5 – K 40/100 M

SW01540208


Applications:

• K 40/100 - Twin-impeller centrifugal pump designed for the realization of pressurization units in water systems.​

• Suitable for sprinkler systems and other general water supply uses. ​

• Ideal for roof and booster to provide direct water supply with complementary Pump PM 1 - 2. BAR to make Automatic Start and stop the residential pump which connected directly to the interior water network​

• Water transfer system with high flow rate Up to 175 liter/min​

• Pumped liquid temperature range From 0 °C Up to 60°C ​

• Maximum ambient temperature: Up to 55°C​

• Box Components : 1.5m wire attached, installation instructions guide​

• Weight : 26.4 KG​

• PACKING DIMENSIONS : Length: 510 mm - Width: 234 mm - Height: 285 mm​

• Warranty :Years Warranty from the date of receipt ​

•  Country Of Origin :Made in Italy

Descriptions:

• Totally enclosed fan cooled motor for protection against rainwater and dust with degree of protection IP44.
• Built-in thermal and current overload protection
• Free of charge power cable , no need to open the terminal box to connect another cable
• Low noise.
• Easy installation.

CONSTRUCTION FEATURES OF THE PUMP:

Pump body and motor support in cast iron. Techno polymer impeller, Carbon/ceramic mechanical seal.
